MYIR | System-On-Modules (SOMs)

MYC-LMA35 System-On-Module

The MYC-LMA35 System-On-Module (SoM) is a compact and reliable solution powered by the Nuvoton NuMicro® MA35D1 processor, featuring dual ARM Cortex-A35 cores running at up to 800MHz and a 180MHz Cortex-M4 core. With up to 512MB DDR3L memory and up to 8GB eMMC storage, this module is equipped with a variety of high-speed interfaces, including Gigabit Ethernet, USB 2.0, CAN FD, and SDIO3.0. Ideal for edge gateway, industrial automation, and HMI applications, the MYC-LMA35 offers advanced multimedia capabilities with its LCD controller, 2D graphics engine, and H.264 video decoder..

  • Detail
  • Special Features
  • Specification

The MYC-LMA35 System-On-Module is designed for applications requiring high-performance processing, multimedia capabilities, and a wide range of connectivity options. The Nuvoton NuMicro® MA35D1 processor, with dual ARM Cortex-A35 cores running at 800MHz and a 180MHz Cortex-M4 core, ensures robust processing power. Integrated 2D graphics and video decoding capabilities (H.264, JPEG) enhance its suitability for display and multimedia applications.

With up to 512MB DDR3L memory and up to 8GB eMMC flash storage, the MYC-LMA35 is well-suited for industrial gateways, smart cockpits, automation control, and other embedded systems. The system also supports extensive peripheral connections through a 252-pin LGA expansion interface, providing versatility for external connectivity and signal routing.

The MYC-LMA35 is built with high-speed interfaces like Gigabit Ethernet, USB 2.0, CAN FD, and SDIO3.0, making it ideal for edge gateway and industrial applications. The integration of advanced display and camera interfaces, including RGB and Parallel CSI, adds to its suitability for HMI and other multimedia applications.

The module is supported by Linux 5.10 and Debian 12 operating systems, with comprehensive software resources, including kernel and driver source code, to help users start development quickly.

  • Processor:

    • Dual ARM Cortex-A35 cores running up to 800MHz

    • ARM Cortex-M4 core running at 180MHz

    • Integrated 2D graphics engine and LCD display controller (up to 1080p@60FPS)

    • On-chip SRAM: 384KB (Cortex-A35: 256KB, Cortex-M4: 128KB)

    • H.264 video decoder and JPEG image decoder

  • Memory:

    • 256MB/512MB DDR3L

    • 256MB NAND Flash / 8GB eMMC Flash

    • 32KB EEPROM

  • Connectivity and Peripherals:

    • Dual Gigabit Ethernet

    • USB 2.0 (2x Host, 1x OTG)

    • 4x CAN FD, 17x UART, 6x I2C, 4x SPI

    • SDIO3.0, 2x I2S, 18x ePWM, RGB and Parallel CSI

    • Up to 190 GPIOs

  • Operating System Support:

    • Linux 5.10

    • Debian 12

  • Working Temperature:

    • Industrial grade: -40°C to 85°C

  • Processor:

    • Nuvoton NuMicro® MA35D1 Processor

    • 2x ARM Cortex-A35 cores up to 800MHz

    • 1x ARM Cortex-M4 core up to 180MHz

    • 2D Graphics Engine, LCD Controller (up to 1080p@60FPS)

    • H.264 Video Decoder, JPEG Image Decoder

  • Memory:

    • 256MB/512MB DDR3L

    • 256MB NAND Flash, 8GB eMMC Flash

    • 32KB EEPROM

  • Storage:

    • 256MB NAND Flash / 8GB eMMC

    • 32KB EEPROM

  • Peripherals:

    • 2x RGMII (Gigabit Ethernet)

    • 2x USB2.0 Host, 1x USB2.0 OTG

    • 4x CAN FD, 17x UART

    • 6x I2C, 4x SPI

    • 1x MIPI CSI, 2x LVDS, 1x RGB

    • 18x ePWM, 4x ADC

    • Up to 190x GPIOs

  • Operating Systems:

    • Linux 5.10

    • Debian 12

  • Power Supply:

    • 5V/1A

  • Working Temperature:

    • -40°C to +85°C (industrial grade)

  • Software Support:

    • Linux 5.10 and Debian 12

    • Full software package and development tools
